How to disconnect and remove the shift cable on Toyota Sequoia?

Remove the negative battery terminal of the vehicle battery, then unbolt the cowl trim panel and the kick panel of the driver's side. After that, remove the upper and the lower steering column covers and the knee bolster trim panel. Unbolt the steering wheel, the front seat and center console to make way for the blocks. Remove the carpeting from the firewall to gain access to and take off the two cable housing mounting retainers and access plate screw on the interior side. It Shifts into neutral, move the steering column shift lever up and released the upper end of the shift cable from the ball socket, while the two tabs of the cable casing are depressed down. Pull the cable out of the cove and disconnect from the cable bracket. Pull back the carpeting and take out the cable housing mounting retainers and the shifter console access plate bolts, then take out the center console and the shifter console. Once more, put the lever into neutral and then pull the shift lever end from the cable, and then take the cap off the casing of the cable. Cable retaining clip should also be pulled out from the center housing. Lift the vehicle with Jacks and support it using jack stands for that purpose, on some models of Sequoia there is rear height control suspension, before lifting it; ensure that the height control in on normal mode and turned off. The nut holding the shift cable to manual lever should be loosened, the shift cable pulled off, and the retainer clip also unscrewed. Unplug the cable on every cable bracket and the bolt that fix cable housing to the body and pull the cable thorough the floor then you can remove. Cabling and removing for both ends of the cable is the opposite of installation whereby the grommet should be positioned correctly and the cable is checked and adjusted if necessary. For change, shift the lever to the neutral position, retract the cable adjuster case boot, slide out the lock piece by pulling the slider away from it, and finally releasing the lock piece. Allow the adjuster case's spring to put pressure on the cable to align it, push the lock piece into the case, and also remove the slider to lock the same. Slide the lever to go through every gears while being keen on checking and realigning the position indicator on the shift lever to match that on the shift cable; if the two does not match then the cable has to be re-adjusted.

Genuine Toyota Sequoia Shift Cable

Transmission Shift Cable

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

10 Shift Cables found

View related parts
Toyota Sequoia Cable Assy, Transmission Control
Part Number: 33820-0C090
$216.68 MSRP: $310.70
You Save: $94.02 (31%)
ADD TO CART
Product Specifications
- Other Name: Shift Control Cable
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2008-2022 Toyota Sequoia | Limited, Platinum, SR5 | 8 Cyl 4.6L, 8 Cyl 4.7L, 8 Cyl 5.7L | 1URFE, 2UZFE, 3URFBE, 3URFE; UCK60L-GKALKA, UCK60L-GKASKA, UCK65L-GKALKA, UCK65L-GKASKA, UPK60L-GKTLKA, UPK60L-GKTSKA, UPK65L-GKTLKA, UPK65L-GKTSKA, USK60L-GKTLKA, USK60L-GKTSKA, USK60L-GKTZKA, USK65L-GKTLGA, USK65L-GKTLKA, USK65L-GKTSGA, USK65L-GKTSKA, USK65L-GKTZGA, USK65L-GKTZKA
View related parts
Toyota Sequoia Transmission Control Cable Assembly
Part Number: 33820-0C030
$175.38 MSRP: $251.48
You Save: $76.10 (31%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assy, Transmission Control (For Column Shift); Shift Control Cable
- Comment: (FOR COLUMN SHIFT)
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2001-2005 Toyota Sequoia | Limited, SR5 | 8 Cyl 4.7L | 2UZFE; UCK35L-GKBLKA, UCK35L-GKBSKA, UCK35L-GKSLKA, UCK35L-GKSSKA, UCK45L-GKBLKA, UCK45L-GKBSKA, UCK45L-GKSLKA, UCK45L-GKSSKA
View related parts
Toyota Sequoia Transmission Control Cable Assembly
Part Number: 33820-0C040
$210.64 MSRP: $302.05
You Save: $91.41 (31%)
ADD TO CART
Product Specifications
- Other Name: Cable Assy, Transmission Control (For Column Shift); Shift Control Cable
- Comment: (FOR COLUMN SHIFT)
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2004-2007 Toyota Sequoia | Limited, SR5 | 8 Cyl 4.7L | 2UZFE; UCK35L-GKBLKA, UCK35L-GKBSKA, UCK35L-GKSLKA, UCK35L-GKSSKA, UCK45L-GKBLKA, UCK45L-GKBSKA, UCK45L-GKSLKA, UCK45L-GKSSKA
View related parts
Toyota Sequoia Transmission Control Cable Assembly
Part Number: 33820-0C080
$208.67 MSRP: $299.22
You Save: $90.55 (31%)
ADD TO CART
Product Specifications
- Other Name: Cable Assy, Transmission Control; Shift Control Cable
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2008-2010 Toyota Sequoia | Limited, Platinum, SR5 | 8 Cyl 4.6L, 8 Cyl 4.7L, 8 Cyl 5.7L | 1URFE, 2UZFE, 3URFBE, 3URFE; UCK60L-GKALKA, UCK60L-GKASKA, UCK65L-GKALKA, UCK65L-GKASKA, UPK60L-GKTLKA, UPK60L-GKTSKA, UPK65L-GKTLKA, UPK65L-GKTSKA, USK60L-GKTLKA, USK60L-GKTSKA, USK60L-GKTZKA, USK65L-GKTLGA, USK65L-GKTLKA, USK65L-GKTSGA, USK65L-GKTSKA, USK65L-GKTZGA, USK65L-GKTZKA
View related parts
Toyota Sequoia Transmission Cable Assembly
Part Number: 33820-0C130
$168.82 MSRP: $240.01
You Save: $71.19 (30%)
ADD TO CART
Product Specifications
- Other Name: Cable Assy, Transmission Control; Shift Control Cable
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2009-2013 Toyota Sequoia | Limited, Platinum, SR5 | 8 Cyl 4.6L, 8 Cyl 4.7L, 8 Cyl 5.7L | 1URFE, 2UZFE, 3URFBE, 3URFE; UCK60L-GKALKA, UCK60L-GKASKA, UCK65L-GKALKA, UCK65L-GKASKA, UPK60L-GKTLKA, UPK60L-GKTSKA, UPK65L-GKTLKA, UPK65L-GKTSKA, USK60L-GKTLKA, USK60L-GKTSKA, USK60L-GKTZKA, USK65L-GKTLGA, USK65L-GKTLKA, USK65L-GKTSGA, USK65L-GKTSKA, USK65L-GKTZGA, USK65L-GKTZKA
View related parts
Toyota Sequoia Shift Control Cable
Part Number: 33820-0C180
$144.02 MSRP: $204.74
You Save: $60.72 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: CABLE ASSY, TRANSMIS; Shift Control Cable
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023-2025 Toyota Sequoia | 6 Cyl 3.5L | V35AFTS; VXKA70L-CRULZA, VXKA70L-CRUSZA, VXKA70L-PSULZA, VXKA70L-PSUSZA, VXKA70L-PSUZZA, VXKA71L-PRULZA, VXKA71L-PRUSZA, VXKA71L-PRUZZA, VXKA72L-CHUSZA, VXKA75L-CRULZA, VXKA75L-CRUSZA, VXKA75L-PSULZA, VXKA75L-PSUSZA, VXKA75L-PSUZZA, VXKA76L-PRULZA, VXKA76L-PRUSZA, VXKA76L-PRUZZA, VXKA77L-CHUSZA, VXKH70L-PSVLZA, VXKH70L-PSVZZA, VXKH71L-PRVLZA, VXKH71L-PRVZZA, VXKH75L-PSVLZA, VXKH75L-PSVUZA, VXKH75L-PSVZZA, VXKH76L-PRVLZA, VXKH76L-PRVZZA, VXKH80L-GKVLZA, VXKH80L-GKVSZA, VXKH80L-GKVZZA, VXKH85L-GKVLZA, VXKH85L-GKVSZA, VXKH85L-GKVZZA
View related parts
Toyota Sequoia Shift Control Cable
Part Number: 33820-0C170
$163.55 MSRP: $232.52
You Save: $68.97 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: CABLE ASSY, TRANSMIS; Shift Control Cable
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023-2025 Toyota Sequoia | 6 Cyl 3.5L | V35AFTS; VXKA70L-CRULZA, VXKA70L-CRUSZA, VXKA70L-PSULZA, VXKA70L-PSUSZA, VXKA70L-PSUZZA, VXKA71L-PRULZA, VXKA71L-PRUSZA, VXKA71L-PRUZZA, VXKA72L-CHUSZA, VXKA75L-CRULZA, VXKA75L-CRUSZA, VXKA75L-PSULZA, VXKA75L-PSUSZA, VXKA75L-PSUZZA, VXKA76L-PRULZA, VXKA76L-PRUSZA, VXKA76L-PRUZZA, VXKA77L-CHUSZA, VXKH70L-PSVLZA, VXKH70L-PSVZZA, VXKH71L-PRVLZA, VXKH71L-PRVZZA, VXKH75L-PSVLZA, VXKH75L-PSVUZA, VXKH75L-PSVZZA, VXKH76L-PRVLZA, VXKH76L-PRVZZA, VXKH80L-GKVLZA, VXKH80L-GKVSZA, VXKH80L-GKVZZA, VXKH85L-GKVLZA, VXKH85L-GKVSZA, VXKH85L-GKVZZA
View related parts
Toyota Sequoia Transmission Control Cable Assembly
Part Number: 33820-0C150
$167.77 MSRP: $238.51
You Save: $70.74 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: CABLE ASSY, TRANSMIS; Shift Control Cable
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023-2025 Toyota Sequoia | 6 Cyl 3.5L | V35AFTS; VXKA70L-CRULZA, VXKA70L-CRUSZA, VXKA70L-PSULZA, VXKA70L-PSUSZA, VXKA70L-PSUZZA, VXKA71L-PRULZA, VXKA71L-PRUSZA, VXKA71L-PRUZZA, VXKA72L-CHUSZA, VXKA75L-CRULZA, VXKA75L-CRUSZA, VXKA75L-PSULZA, VXKA75L-PSUSZA, VXKA75L-PSUZZA, VXKA76L-PRULZA, VXKA76L-PRUSZA, VXKA76L-PRUZZA, VXKA77L-CHUSZA, VXKH70L-PSVLZA, VXKH70L-PSVZZA, VXKH71L-PRVLZA, VXKH71L-PRVZZA, VXKH75L-PSVLZA, VXKH75L-PSVUZA, VXKH75L-PSVZZA, VXKH76L-PRVLZA, VXKH76L-PRVZZA, VXKH80L-GKVLZA, VXKH80L-GKVSZA, VXKH80L-GKVZZA, VXKH85L-GKVLZA, VXKH85L-GKVSZA, VXKH85L-GKVZZA
View related parts
Toyota Sequoia Shift Control Cable Assembly
Part Number: 33820-0C160
$168.59 MSRP: $239.67
You Save: $71.08 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: CABLE ASSY, TRANSMIS; Shift Control Cable
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023-2025 Toyota Sequoia | 6 Cyl 3.5L | V35AFTS; VXKA70L-CRULZA, VXKA70L-CRUSZA, VXKA70L-PSULZA, VXKA70L-PSUSZA, VXKA70L-PSUZZA, VXKA71L-PRULZA, VXKA71L-PRUSZA, VXKA71L-PRUZZA, VXKA72L-CHUSZA, VXKA75L-CRULZA, VXKA75L-CRUSZA, VXKA75L-PSULZA, VXKA75L-PSUSZA, VXKA75L-PSUZZA, VXKA76L-PRULZA, VXKA76L-PRUSZA, VXKA76L-PRUZZA, VXKA77L-CHUSZA, VXKH70L-PSVLZA, VXKH70L-PSVZZA, VXKH71L-PRVLZA, VXKH71L-PRVZZA, VXKH75L-PSVLZA, VXKH75L-PSVUZA, VXKH75L-PSVZZA, VXKH76L-PRVLZA, VXKH76L-PRVZZA, VXKH80L-GKVLZA, VXKH80L-GKVSZA, VXKH80L-GKVZZA, VXKH85L-GKVLZA, VXKH85L-GKVSZA, VXKH85L-GKVZZA
View related parts
Toyota Sequoia Cable Assembly, Parking Lock
Part Number: 33880-0C020
Product Specifications
- Other Name: Cable Assy, Parking Lock (For Column Shift); Cable, Lock Cable
- Comment: (FOR COLUMN SHIFT)
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2001-2007 Toyota Sequoia | Limited, SR5 | 8 Cyl 4.7L | 2UZFE; UCK35L-GKBLKA, UCK35L-GKBSKA, UCK35L-GKSLKA, UCK35L-GKSSKA, UCK45L-GKBLKA, UCK45L-GKBSKA, UCK45L-GKSLKA, UCK45L-GKSSKA

Toyota Sequoia Shift Cable

The Toyota Sequoia Shift Cable allows the driver to control the transmission by simply moving the gear lever. The cable accomplishes this by converting a hand motion into a gear position that the transmission understands, granting drivers confidence when operating their vehicle. The Shift Cable is the connection between the lever that mounts to the floor and the manual lever of the transmission. It pulls or pushes in response to a button on the handle. This means that park, reverse, neutral, drive, or low only engages when it is intended to. The Sequoia's early rigid linkage rods are similar to older pickups, but manufacturers quickly switched to the flexible Shift Cable since it reduces vibration, fits neatly below the console, and works with electronic shift interlocks that require the brake pedal before leaving park. Modern sport utility vehicles involve the Shift Cable, a floor shifter with a spring button that prevents bumps while imparting a positive feel not found on the column setups of Toyota trucks. As time goes on, the cable stretches, bends, or breaks after countless shifts. This causes the lever to go loose or refuse to engage into gear. The replacement, which takes under an hour with basic tools, restores crisp selection. The recent Shift Cable weighs less and resists dirt sealed within its jacket. It also easily routes around the bulky 4WD components unique to the Sequoia platform. Thus, compared to rod linkages, it keeps Toyota owners shifting smoothly for years.

If you are in demand for superior quality and affordable OEM Toyota Sequoia Shift Cable, then shop with us! We own a wide range of the reduced-priced genuine Toyota Sequoia Shift Cable. You can purchase in confidence as all parts come with a manufacturer's warranty. Any issues with our products? No need to worry as we have a hassle-free return policy to guide you every step of the way.

Toyota Sequoia Shift Cable Parts Questions & Experts Answers

Cable Assy, Transmission Control
33820-0C090
Q: How to disconnect and remove the shift cable on Toyota Sequoia?
A:
Remove the negative battery terminal of the vehicle battery, then unbolt the cowl trim panel and the kick panel of the driver's side. After that, remove the upper and the lower steering column covers and the knee bolster trim panel. Unbolt the steering wheel, the front seat and center console to make way for the blocks. Remove the carpeting from the firewall to gain access to and take off the two cable housing mounting retainers and access plate screw on the interior side. It Shifts into neutral, move the steering column shift lever up and released the upper end of the shift cable from the ball socket, while the two tabs of the cable casing are depressed down. Pull the cable out of the cove and disconnect from the cable bracket. Pull back the carpeting and take out the cable housing mounting retainers and the shifter console access plate bolts, then take out the center console and the shifter console. Once more, put the lever into neutral and then pull the shift lever end from the cable, and then take the cap off the casing of the cable. Cable retaining clip should also be pulled out from the center housing. Lift the vehicle with Jacks and support it using jack stands for that purpose, on some models of Sequoia there is rear height control suspension, before lifting it; ensure that the height control in on normal mode and turned off. The nut holding the shift cable to manual lever should be loosened, the shift cable pulled off, and the retainer clip also unscrewed. Unplug the cable on every cable bracket and the bolt that fix cable housing to the body and pull the cable thorough the floor then you can remove. Cabling and removing for both ends of the cable is the opposite of installation whereby the grommet should be positioned correctly and the cable is checked and adjusted if necessary. For change, shift the lever to the neutral position, retract the cable adjuster case boot, slide out the lock piece by pulling the slider away from it, and finally releasing the lock piece. Allow the adjuster case's spring to put pressure on the cable to align it, push the lock piece into the case, and also remove the slider to lock the same. Slide the lever to go through every gears while being keen on checking and realigning the position indicator on the shift lever to match that on the shift cable; if the two does not match then the cable has to be re-adjusted.
